2-Way Miniature Water Solenoid Valve: Factory Direct Pricing & High-Performance Reliability

1. Heat Management & Duty Cycle

• Continuous Operation: This series is rated for short-to-medium burst operations. For continuous 24/7 activation, we recommend using a PWM (Pulse Width Modulation) controller to reduce holding current after initial actuation.

• Surface Temperature: Normal operation may result in surface temperatures up to 50°C. Ensure adequate ventilation or heat-sinking if integrated into tightly sealed enclosures.

2. Fluidic System Integrity

• Filtration Requirements: To maintain the ≥200,000 cycle service life, ensure the fluid media is filtered to at least 50 microns to prevent debris from compromising the internal seal.

• Pressure Spikes: While rated for 100 KPa, avoid sudden high-pressure surges (Water Hammer) by utilizing soft-start plumbing or bypass valves in high-flow systems.

3. Electrical Integration

• Polarity: As a DC solenoid, ensure correct wiring polarity to optimize response time and prevent back-EMF interference with sensitive control electronics.

• Voltage Tolerance: Maintains stable performance within a ±10% voltage fluctuation range. Operating significantly above the rated voltage may decrease solenoid life due to excessive heat.

4. Mechanical Mounting

• Orientation: For optimal airtightness and debris management, mounting the valve with the actuator facing upward is recommended.

• Weight Consideration: At approximately 32g, the valve is ideal for portable devices but should be secured with standard mounting brackets to avoid stress on the fluid nozzles.
