095 Micro Diaphragm Vacuum Pump for Aerosolizer and Beauty Device

Short Description:

095-X micro diaphragm vacuum pump delivers >60KPA vacuum for aerosolizers, beauty devices, and disinfection guns. This 3.7V/6V/12V DC pump provides 0.3-1.5LPM flow with ≤60dB noise. Compact 87.3g design features medical-grade durability (>30k cycles). Ideal for skincare instruments, spray systems, and pneumatic tools requiring precise pressure control. Supports custom OEM configurations for voltage and airflow specifications. Certified components ensure reliable operation in continuous-use applications.

Product Name: 095-X Micro Diaphragm Vacuum Pump

Operating Voltage: 3.7V / 6V / 12V DC

Max Vacuum Pressure: >60 KPA (450 mmHg)

Flow Rate (No Load): 0.3 - 1.5 LPM

Noise Level: ≤60 dB (30 cm away)

Application: Aerosolizer, Beauty Device, Disinfection Gun, Massager

PDF Send email to us

Product Detail

Video

Product Tags

Customized Service

To provide customers with quality products and satisfactory service

MOQ 500pcs

Fast Delivery

Customized Sample

Excellent Quality

Competitive Price

Modern Testing Equipment

PYP095-X Micro Vacuum Pump

The PYP095-X micro diaphragm vacuum pump delivers >60KPA strong suction for aerosolizers, beauty devices, and spray guns. Featuring compact 87g design, multi-voltage (3.7V/6V/12V) operation, and ≤60dB quiet performance. With >30,000-cycle lifespan and precise airflow (0.3-1.5LPM), ideal for medical, cosmetic, and disinfection OEM applications.

Vacuum Pump for Beauty Device

Professional research

Long Lifetime

(※ Click this button to inquiry more)

Product Information

PYP095-X Micro Vacuum Pump
*OEM/ODM Service available, contact us to get more details!
Rate Voltage	DC 3.7V	DC 6V	DC 12V
Rate Current	≤500mA	≤300mA	≤150mA
Power	1.8w	1.8w	1.8w
Air Tap O.D	φ 5.4mm
Vacuum flow rate Flow	2.5-6.5 LPM
Maximum Vacuum Pressure	≥60 kpa (450mmHg)
Noise Level	≤60db (30cm away)
Life Test	≥30,000Times(ON10秒，OFF5秒)
Net Weight	87.3g
Inflation Time	<10s(From 0 to 300mmHg in a500cc tank)
Leakage	<3.0mmHg/min(from 300mmHg in a 500cc tank)
