Brushless DC Small Electric Air Pump – 310A Micro Diaphragm | Pincheng Motor

Short Description:

Brushless DC air pump motor technology powers our small air pump electric devices, delivering unmatched efficiency and durability. This DC small air pump electric is ideal for medical equipment, portable electronics, and DIY projects. The small portable air pump offers ultra-quiet operation, long lifespan, and reliable performance for applications requiring compact, maintenance-free airflow solutions.

Model Number: PYP310A-XA (Brushless motor)

Flow Rate: 0.5-3.0 LPM

Maximum Pressure: ≥60Kpa (450mmHg)

Noise Level: ≤60db (30cm away)

Operating Temperature Range: -20-70 ℃

Protection Rating: IP64

Send email to us

Product Detail

Video

Product Tags

Customized Service

To provide customers with quality products and satisfactory service

MOQ 500pcs

Fast Delivery

Customized Sample

Excellent Quality

Competitive Price

Modern Testing Equipment

PYP310-XA

Small Brushless DC Air Pump Motor

PYP310A - XA Brushless DC micro air pump for home appliances & medical devices. Features silent operation, long lifespan, and efficient diaphragm design. Ideal for inflation applications.

Brushless DC Small Electric Air Pump

Professional research

Long Lifetime

(※ Click this button to inquiry more)

Product Information

PYP310-XA(Brushless Motor）Brushless Dc Air Pump Motor
*OEM/ODM Service available, contact us to get more details!
Rate Voltage	DC 3V	DC 6V	DC 9V	DC 12V
Rate Current	≤800mA	≤400mA	≤260mA	≤200mA
Power	2.4w	2.4w	2.4w	2.4w
Air Tap O.D	φ 4.3mm
Water Flow	0.5-3.0 LPM
Inflation Time	＜10s (from 0 to 300mmHg in a 500cc tank)
Noise Level	≤60db (30cm away)
Life Test	≥2500 Hrs (Continue)
Leakage	＜3.0mmHg/min (from 0 to 300mmHg in a 500cc tank)
Net weight	36g
